Description

EPEVER iTracer Mppt solar charge controller

Solar charge controller seri iTracer-ND menerapkan teknologi Mppt dengan Pelacakan Titik Daya Maksimum dengan sinkron multifase (MSRT) dan desain yang solid. Dengan arsitektur prosesor dual-core dan algoritma sebagai pengontrol MPPT yang canggih, produk dalam seri ini memiliki fitur kecepatan respons tinggi, keandalan tinggi, untuk standar industri yang tinggi.

Seri iTracer-ND mendukung daya hingga 800Wp PV dalam sistem 12V, 1600Wp dalam sistem 24V, 2400W dalam sistem 36V, dan 3200Wp dalam sistem 48V.

Standard Features:

• Advanced Maximum Power Point Tracking (MPPT) technology, with efficiency no less than 99.5%
• High quality components, perfecting system performance, with maximum conversion efficiency of 98% and full load efficiency of 97%
• MSRT, realizing high conversion efficiency in the situation of low charge power
• Reliable automatic limit function of maximum PV input power, ensuring no overload
  Wide MPP operating voltage range
• High-speed and high-powered dual-core processor architecture, improving system response speed, optimizing system performance
• Die-cast aluminum case for heat dissipating, ensuring excellent heat dissipation characteristic 12/24/36/48VDC automatically identifying system voltage or user-de­ned working voltage
• Concise human-computer interactive interface, convenient multiple combination keys, dynamically displaying system operating data and working condition
• Multiple load control modes: manual control, light ON/OFF, light on+timer and time control
  Support 4 charging options: Sealed, Gel, Flooded and User
• Battery temperature compensation function Real-time energy statistics function With RS-485, RS-232 communication bus interface and Modbus communication protocol, it is available to meet various communication requirements in different situations

ELECTRONIC Protections :
– PV short circuit protection
– PV over current protection
– PV reverse polarity protection
– Battery over voltage protection
– Battery over discharge protection
– Battery reverse polarity protection
– Load overload protection
– Load short circuit protection
– Battery overheating protection
– Controller overheating protection
